— BerryAlloc · Zenn Loose Lay 55
Zenn Loose Lay 55 — loose-lay vinyl, only 4.5 mm thick
The Zenn collection by BerryAlloc impresses with natural decors and lively colour play. Zenn is available as planks or tiles, in herringbone or concrete look, for gluing down, as click vinyl or for loose-lay installation.
Zenn Loose Lay 55 is the fast solution for renovation and new builds: only 4.5 mm build height, a 0.55 mm wear layer and an anti-skid backing that keeps the planks (1219.2 × 228.6 mm) firmly in place — installed loose, partially tackified or fully tackified. Waterproof, scratch resistant, slip resistant, extremely stable, easy to maintain and suitable for underfloor heating and cooling.
Loose Lay 55 Plank
1219.2 × 228.6 × 4.5 mm · wear layer 0.55 mm · class 23/33/42
Loose Lay 55 Tile
600 × 600 × 4.5 mm in concrete look — same properties
Installation
Loose up to 15 m² · tackified up to 500 m²
Other Zenn variants
Click Comfort 30 | 55 and Gluedown 30 | 55
Six reasons for BerryAlloc Zenn Loose Lay 55.
Loose Lay Installation
Fast, fuss-free installation: loose, partially tackified or fully tackified — ideal for raised floors and areas where easy replacement is a must.
Anti-Skid Backing
The anti-skid backing and the fibreglass layer keep the elements firmly in place and add extra stability.
Waterproof
Vinyl is insensitive to moisture — suitable for kitchens, bathrooms and entrance areas.
Scratch Resistant & Durable
0.55 mm wear layer with protective lacquer for a lasting look — use class 23 / 33 / 42.
Slip Resistant
Slip resistance R10 and class DS — safe footing in everyday use.
Underfloor Heating & Cooling
Suitable for underfloor heating and cooling up to max. 27 °C surface temperature, electric systems up to max. 90 W/m².
01
Technical Specifications — BerryAlloc Zenn Loose Lay 55 Plank
Plank dimensions1219.2 × 228.6 mm
Total thickness4.5 mm
Wear layer0.55 mm
Use class23 Residential · 33 Commercial · 42 Industrial
InstallationLoose Lay — loose or tackified
BackingAnti-skid backing with fibreglass layer
BevelMicro V4 — 4 sides
Packaging planks10 pieces / 2.79 m²
Pallet planks40 packs / 111.48 m²
Installation up to 15 m²Loose laid (without adhesive)
Installation up to 60 m²Tackifier every 4 m and along the room perimeter
Installation up to 500 m²Fully tackified
Expansion gapNot permitted
Additional underlayNot permitted
Thermal resistance0.040 m²K/W
Underfloor heating / coolingSuitable · max. 27 °C · electric max. 90 W/m²
Slip resistanceR10 · class DS
Impact sound reductionΔLw = 8 dB
Fire behaviourBfl-s1
Residual indentation≤ 0.10 mm — pass
Dimensional stability≤ 0.15 % — pass
Light fastness≥ 6
Antistatic≤ 2 kV
ManufacturerBerryAlloc, Belgium
02
Further Information
Manufacturer's website
Detailed technical data, warranty conditions, certificates and further product information are available directly on the manufacturer's website: BerryAlloc Zenn.
